The BAFANG BBS02B/BBS-HD mid-drive kit earns the top spot in this roundup because it delivers the most balanced ride quality of any option here — torque that feels natural, clean weight distribution, and compatibility with a huge range of bikes. If budget matters more than refinement, the 48V 1000W rear hub kits offer serious power for far less money, while the BAFANG 48V 500W front kit with battery is the easiest entry point for first-time converters. The main tradeoff in this category comes down to hub motors versus mid-drives versus gas engines: hub kits are cheap and simple but change how the bike handles, mid-drives feel like a factory e-bike but cost more, and 2-stroke gas kits deliver range without charging but bring noise, smell, and maintenance. Battery inclusion is another dividing line — several kits ship without one, which can change the true cost of your build. Keep reading for the full breakdown of all 14 kits and which one fits your bike, budget, and riding style.
Get bike and ride gear delivered free — and shop member deals
- Fast, free delivery on millions of items
- Access to Prime Big Deal Days deals on October 6–7
- Prime Video, Amazon Music and more included
Key Takeaways
- Mid-drive BAFANG kits (BBS02B/BBS-HD) beat comparable hub motors on ride feel and hill climbing because they use your bike’s gears — but you pay a premium and need a standard bottom bracket to install them.
- Most 1000W and 2000W hub kits in this lineup ship without a battery, so the sticker advantage over the BAFANG 500W kit-with-battery shrinks once you factor in a separate 48V pack.
- The 2-stroke gas kits (110cc and 80cc) are the only options here immune to charging infrastructure, but they demand real mechanical skill, regular maintenance, and tolerance for noise — they suit tinkerers, not commuters.
- Fat-tire riders on 20×4-inch wheels have only two real options (HuaShuani and LTIGOAW 2000W kits), and choosing between them comes down to included components and controller quality rather than raw power, which is identical on paper.
- Front-wheel kits like the Ktaxon 24-inch and BAFANG 500W are the simplest installs and keep your existing drivetrain untouched, but they struggle on steep hills and can lose traction in wet conditions compared to rear hub or mid-drive setups.
| 26-Inch 48V 1000W Rear Hub Electric Bike Conversion Kit |  | Best Overall for 26-Inch Builds | Wheel size: 26 inches | Motor: 48V 1000W brushless gearless rear hub | Motor speed: 440 RPM | VIEW LATEST PRICE | See Our Full Breakdown |
| 110cc 2-Stroke Bicycle Engine Conversion Kit for 26- and 28-Inch Bikes |  | Best Gas-Powered Conversion | Engine type: 2-stroke, single-cylinder | Displacement: 110cc | Cooling: Air-cooled | VIEW LATEST PRICE | See Our Full Breakdown |
| HuaShuani 48V 2000W Electric Bike Rear Wheel Hub Motor Conversion Kit for 20 x 4-Inch Wheels |  | Best for Fat-Tire Builds with Display Controls | Voltage: 48V | Power: 2000W | Wheel size: 20 x 4 inches | VIEW LATEST PRICE | See Our Full Breakdown |
| 26-Inch 48V 1000W Rear-Wheel Electric Bike Conversion Kit |  | Best for a Simple 26-Inch Hub Setup | Wheel size: 26 inches | Voltage: 48V | Motor power: 1000W | VIEW LATEST PRICE | See Our Full Breakdown |
| LTIGOAW 20-Inch 48V 2000W Rear Hub Motor E-Bike Conversion Kit for 20×4-Inch Tires |  | Best High-Torque Fat-Tire Pick | Voltage: 48V | Motor power: 2000W | Motor type: Brushless, gearless rear hub | VIEW LATEST PRICE | See Our Full Breakdown |
| Bikerid 80cc 2-Stroke Bicycle Engine Conversion Kit with Speedometer |  | Best Gas-Powered Starter Kit | Engine: 80cc, 2-stroke | Compatible bicycle sizes: 26–28 inches | Claimed maximum speed: 38 km/h | VIEW LATEST PRICE | See Our Full Breakdown |
| BAFANG 48V 500W/750W Front or Rear Wheel Hub Motor E-Bike Conversion Kit |  | Best Configurable Hub-Motor Pick | Motor options: G020 48V 500W front or rear; G0900 48V 750W rear | Torque: 65 N·m (G020); 80 N·m (G0900) | Maximum speed: 40 km/h (G020); 45 km/h (G0900) | VIEW LATEST PRICE | See Our Full Breakdown |
| 48V 1000W Rear Hub Motor Conversion Kit for 26-Inch Bikes |  | Best for a 26-Inch Rear-Wheel Conversion | Voltage: 48V | Power: 1000W | Wheel size: 26 inches | VIEW LATEST PRICE | See Our Full Breakdown |
| Varstrom 48V 1000W/1500W Front or Rear Hub Motor E-Bike Conversion Kit |  | Best High-Power Hub-Motor Range | Voltage: 48V | Motor options: 1000W front; 1000W or 1500W rear | Maximum torque: 66 N·m (1000W); 78 N·m (1500W) | VIEW LATEST PRICE | See Our Full Breakdown |
| BAFANG BBS02B/BBS-HD Mid-Drive Electric Bike Conversion Kit |  | Best for Torque-Focused Mid-Drive Builds | Motor options: 500W, 750W, or 1000W | Torque options: 100, 120, or 160 N·m | Claimed maximum speed: Up to 45 km/h | VIEW LATEST PRICE | See Our Full Breakdown |
| BAFANG BBS02B 48V 750W Mid-Drive Electric Bike Conversion Kit |  | Best for Hill Climbing | Motor: BAFANG BBS02B mid-drive | Voltage: 48V | Power: 750W | VIEW LATEST PRICE | See Our Full Breakdown |
| BAFANG 48V 500W Front Wheel E-Bike Conversion Kit with Battery |  | Best for DIY Beginners | Motor type: Brushless geared front hub | Voltage: 48V | Power: 500W | VIEW LATEST PRICE | See Our Full Breakdown |
| 48V 1500W Electric Bike Conversion Kit with 20-Inch Rear Hub Motor |  | Best for Small-Wheel Builds | Voltage: 48V | Motor power: 1500W | Wheel size: 20 inches | VIEW LATEST PRICE | See Our Full Breakdown |
| Ktaxon 48V 1000W 24-Inch Front-Wheel E-Bike Conversion Kit |  | Best for 24-Inch Front-Wheel Conversions | Motor power: 1000W | Voltage: 48V | Wheel size: 24 inches | VIEW LATEST PRICE | See Our Full Breakdown |
More Details on Our Top Picks
26-Inch 48V 1000W Rear Hub Electric Bike Conversion Kit
This kit is my most balanced pick for a rider converting a compatible 26-inch bike with 135 mm rear spacing. Its 1000W rear hub pairs pedal assist with a thumb throttle, while the included power-off brake levers cut motor power when braking. That gives it a more complete everyday setup than the 26-Inch 48V 1000W Rear-Wheel Electric Bike Conversion Kit, whose supplied details focus on the motor and assembly accessories. The stated top speed of up to 33 mph is a claim, not a guarantee of typical riding speed, and the 45 N·m torque is less than the LTIGOAW fat-tire kit’s 65 N·m. The main compromise is that you must source a compatible battery separately, and bikes with different wheel or dropout dimensions are out.
Pros:- Includes pedal-assist sensor, thumb throttle, and power-off brake levers
- Controller bag and mounting hardware are included
- Designed for 26-inch wheels and 135 mm rear dropout spacing
- Two-year warranty
Cons:- Battery is not included
- Fit is limited by wheel size and rear dropout spacing
- The stated speed of up to 33 mph may not reflect riding conditions
Best for: Riders converting a 26-inch bike with 135 mm rear dropout spacing who want both pedal assist and throttle control.
Not ideal for: Owners of fat-tire, 20-inch, or differently spaced frames, and buyers who need a battery in the kit.
- Wheel size:26 inches
- Motor:48V 1000W brushless gearless rear hub
- Motor speed:440 RPM
- Stated maximum speed:Up to 33 mph
- Torque:45 N·m
- Rear dropout spacing:135 mm
- Maximum recommended load:265 pounds
- Battery:Not included
Our verdict“Choose it for a relatively complete 26-inch rear-hub conversion when you already have or plan to source a compatible battery.”
110cc 2-Stroke Bicycle Engine Conversion Kit for 26- and 28-Inch Bikes
This is the outlier for riders who specifically want a gas-powered bicycle rather than an electric assist system. Its 110cc two-stroke engine kit includes the fuel tank, carburetor, exhaust, controls, chain, and mounting parts, so it covers more of the engine setup than the electric kits here, which depend on a separately sourced battery. The tradeoff is a more involved installation: the frame needs a V shape and enough space for the engine, and the product recommends professional fitting. Unlike the quieter hub-motor approach of the 26-Inch 48V 1000W Rear Hub Electric Bike Conversion Kit, this engine requires gasoline mixed with oil at a specified ratio and uses a foot-pedal starting method. Its stated speed is not enough on its own to predict real-world performance or legal suitability.
Pros:- Includes engine, fuel tank, carburetor, exhaust, controls, chain, and mounting accessories
- Designed for many 26- and 28-inch bicycles
- Air-cooled engine with CDI ignition
- Includes a 2 L fuel tank
Cons:- Professional installation is recommended
- Frame shape and available triangle space determine compatibility
- Requires gasoline and oil mixed at a specified ratio
Best for: Mechanically confident riders seeking a gasoline engine conversion for a compatible 26- or 28-inch bicycle with a V-shaped frame.
Not ideal for: Riders who want a low-maintenance electric setup, quiet operation, or a straightforward installation on a frame with limited space.
- Engine type:2-stroke, single-cylinder
- Displacement:110cc
- Cooling:Air-cooled
- Maximum power:3 kW at 6000 rpm
- Stated maximum speed:55 km/h (34.155 mph)
- Fuel tank capacity:2 L
- Starting method:Foot pedal
- Net weight:11.2 kg (24.69 pounds)
Our verdict“Pick this only if you want a gasoline-powered build and have a suitable frame and installation support.”
HuaShuani 48V 2000W Electric Bike Rear Wheel Hub Motor Conversion Kit for 20 x 4-Inch Wheels
The HuaShuani is aimed at a narrow but clear buyer: someone fitting a 20 x 4-inch wheel who wants an LCD readout and multiple riding modes. The display reports speed, mileage, power, voltage, current, and fault information, which gives more system feedback than the supplied details for the 26-Inch 48V 1000W Rear Hub Electric Bike Conversion Kit. Its controller can operate in Hall or non-Hall mode, a potentially useful fallback if a compatible component fails. The listed 34 mph is a no-load speed, so I would not treat it as a promise for riding. Compared with the similarly sized LTIGOAW kit, this one lists five speed settings and Hall/non-Hall operation, but its 30-day warranty is much shorter than LTIGOAW’s two years.
Pros:- LCD displays speed, mileage, power, voltage, current, and fault information
- Offers pedal-assist and pure-electric modes
- Controller supports Hall and non-Hall operation
- Five speed settings
Cons:- Warranty is limited to 30 days
- The listed 34 mph is a no-load figure and may differ under riding conditions
- Designed for a specific 20 x 4-inch wheel size
Best for: Fat-tire bike owners with 20 x 4-inch wheels who value an information-rich LCD and selectable electric riding modes.
Not ideal for: Buyers seeking a longer warranty, a clearly itemized set of included controls, or compatibility beyond 20 x 4-inch wheels.
- Voltage:48V
- Power:2000W
- Wheel size:20 x 4 inches
- Motor speed:550 rpm
- Listed no-load speed:34 mph
- Speed settings:5
- Riding modes:Pedal assist and pure electric
- Warranty:30 days
Our verdict“Choose it for a 20 x 4-inch fat-tire build when display detail and controller operating modes matter more than warranty length.”
26-Inch 48V 1000W Rear-Wheel Electric Bike Conversion Kit
This kit suits riders who want a 1000W rear hub for a 26-inch bike and are comfortable handling a DIY installation. Its brushless, toothless motor is described as quieter and easier to maintain, and the product lists a load capacity of 120 kg. Against the more fully itemized 26-Inch 48V 1000W Rear Hub Electric Bike Conversion Kit, however, the supplied details here say less about rider controls: they do not specify a throttle, pedal-assist sensor, or power-off brake levers. That makes the other 26-inch kit the clearer choice for someone comparing included control components. The stated speed reaches 53 km/h, but real riding speed can vary. This kit also has no listed battery, and its compatibility claim remains tied to suitable 26-inch bikes.
Pros:- 1000W brushless, toothless rear hub motor
- Motor is described as quieter and easier to maintain
- Lists a 120 kg load capacity
- Includes assembly accessories
Cons:- Requires DIY assembly
- Compatibility is limited to suitable 26-inch bikes
- Supplied details do not specify a battery or rider control components
Best for: DIY-minded riders with a compatible 26-inch bike who prioritize a brushless rear hub and can confirm the controls and other parts they need.
Not ideal for: Buyers who want clearly specified pedal assist, throttle, brake cutoffs, or a battery included in the kit.
- Wheel size:26 inches
- Voltage:48V
- Motor power:1000W
- Motor type:Brushless, toothless rear-wheel hub motor
- Stated maximum speed:Up to 53 km/h
- Torque:45 N·m
- Load capacity:120 kg (264.55 pounds)
- Efficiency:Over 80%
Our verdict“Consider it for a DIY 26-inch build after confirming that the kit includes the controls and battery setup you need.”
LTIGOAW 20-Inch 48V 2000W Rear Hub Motor E-Bike Conversion Kit for 20×4-Inch Tires
For a compatible 20 x 4-inch fat-tire bike, LTIGOAW combines a 2000W brushless, gearless hub with stated torque of 65 N·m. That higher torque figure gives it a stronger spec-sheet case for riders prioritizing pulling force than the HuaShuani 20 x 4-inch kit, which lists the same motor speed and a 34 mph figure but does not provide a torque rating. LTIGOAW also includes an LCD, thumb throttle, controller, and brake levers with power-off function, while its stated noise level is below 55 dB. The tradeoffs are fit and speed uncertainty: the kit is specific to 20 x 4-inch tires, and its 34 mph claim may not match ordinary riding conditions. It also does not list a battery among the included components.
Pros:- Lists 65 N·m of torque from a 2000W motor
- Includes LCD display, thumb throttle, controller, and two brake levers
- Power-off brake handles are specified for V-brakes and disc brakes
- Two-year warranty and stated noise below 55 dB
Cons:- Designed for 20 x 4-inch tires
- Battery is not listed among included components
- The stated 34 mph maximum may not reflect typical riding conditions
Best for: Fat-tire bike owners with 20 x 4-inch tires who want a high-torque hub kit with a display, throttle, and brake cutoffs.
Not ideal for: Riders with other wheel sizes or buyers who need the battery supplied and the riding speed clearly established.
- Voltage:48V
- Motor power:2000W
- Motor type:Brushless, gearless rear hub
- Compatible tire size:20 x 4 inches
- Torque:65 N·m
- Motor speed:550 rpm
- Stated maximum speed:34 mph (55 km/h)
- Warranty:2 years
Our verdict“Choose LTIGOAW for a compatible 20 x 4-inch build when its higher listed torque and included controls fit your priorities.”
Bikerid 80cc 2-Stroke Bicycle Engine Conversion Kit with Speedometer
The Bikerid kit is the gas-engine pick for riders with a compatible 26- to 28-inch bicycle who want a conversion centered on an included engine and hardware. Its speedometer and installation manual make the package more self-contained than the BAFANG 48V 500W/750W hub kit, where battery and display options vary by configuration. The seller claims a top speed of 38 km/h and a 2–3 hour assembly time, but those figures should be treated as estimates rather than a promise for every build. The tradeoff is the two-stroke setup: it is a different fit from the electric assist offered by the other kits, and frame compatibility still needs checking. I would shortlist it for a conventional bicycle conversion, but skip it if you want electric pedal assist or a more predictable fit process.
Pros:- Designed for compatible 26- to 28-inch bicycles
- Includes the engine, carburetor, drive components, and mounting hardware
- Speedometer is included
- Installation manual is included
Cons:- Compatibility can vary with the bicycle frame
- Claimed speed and assembly time are seller-provided estimates
Best for: Riders with a compatible 26- to 28-inch bicycle who specifically want a gas-powered conversion and an included speedometer
Not ideal for: Riders seeking electric pedal assist or those whose bicycle frame and mounting points have not been confirmed compatible
- Engine:80cc, 2-stroke
- Compatible bicycle sizes:26–28 inches
- Claimed maximum speed:38 km/h
- Included accessories:Muffler, drive chain, sprocket, speedometer, mounting brackets, grips, carburetor, spark plug, bolts, gaskets, installation manual
- Claimed assembly time:2–3 hours
- Exterior:Polished
- Model:RYTGHJ562
Our verdict“Choose the Bikerid if you want a gas-engine conversion package for a compatible 26- to 28-inch bicycle and do not need electric assist.”
BAFANG 48V 500W/750W Front or Rear Wheel Hub Motor E-Bike Conversion Kit
BAFANG earns a place for buyers who want a choice of front or rear hub drive and moderate power options across common wheel sizes. The 500W G020 offers front or rear configurations, while the 750W G0900 is rear-only and has higher listed torque; that makes this lineup more adaptable than the 26-inch-only 1000W rear hub kit. Pedal assist, walk assist, and full-electric modes also give riders more ways to use the bike than a throttle-only build. The selection requires careful fit checks: dropout dimensions and cassette compatibility matter, and carbon, wooden, fat-bike, and thru-axle frames are excluded. Battery, charger, and display availability depends on configuration, so the listed kit may not be a complete ride-ready package. I would choose it for fit flexibility within its compatibility limits, not for maximum output.
Pros:- Offers front and rear 500W options plus a 750W rear option
- Supports several common wheel sizes
- Includes pedal assist, walk assist, and full-electric riding modes
- Brake lever or sensor can cut motor power while braking
Cons:- Battery, charger, and display may be optional
- Not compatible with carbon or wooden frames, fat bikes, or thru-axle bicycles
- Fit depends on dropout dimensions and cassette compatibility
Best for: Commuters with a compatible standard-frame bicycle who want to choose between front or rear drive and retain pedal-assist options
Not ideal for: Owners of carbon, wooden, fat, or thru-axle bicycles, or buyers expecting every configuration to include a battery and display
- Motor options:G020 48V 500W front or rear; G0900 48V 750W rear
- Torque:65 N·m (G020); 80 N·m (G0900)
- Maximum speed:40 km/h (G020); 45 km/h (G0900)
- Compatible wheel sizes:20, 26, 27.5, 28, or 29 inches; 700C
- Dropout widths:Front up to 100 mm; rear 135–142 mm
- Cassette compatibility:Up to 9 speeds
- Riding modes:Pedal assist, walk assist, full electric
- Efficiency:≥80%
Our verdict“Pick this BAFANG hub kit if your bike passes the fit checks and you value drive and riding-mode choices over the higher listed output of the Varstrom kit.”
48V 1000W Rear Hub Motor Conversion Kit for 26-Inch Bikes
This kit keeps the build focused: a 48V, 1000W gearless rear hub in a 26-inch wheel, with a thumb throttle, pedal-assist sensor, and power-off brake handle. That straightforward specification makes it easier to assess than the BAFANG 48V 500W/750W kit, which offers more drive and wheel choices but a wider range of configurations to check. The battery is not included, and the motor wheel weighs 10.4 kg, so buyers need to account for both the separate power source and added wheel mass. Its 45 N·m torque and claimed 53 km/h maximum speed are product specifications, not a guarantee of real-world performance. I would consider it only for a compatible 26-inch rear-wheel build; Varstrom is the more adaptable choice if you need other wheel sizes or front drive.
Pros:- Combines a 1000W rear hub motor with a thumb throttle and pedal-assist sensor
- Power-off brake handle can cut motor power during braking
- Uses a 36-spoke wheel
- Specifies compatibility with 48V 17–20Ah batteries
Cons:- Battery is not included
- Fit is limited to 26-inch bicycles with a suitable rear fork
- The 10.4 kg motor wheel adds substantial wheel weight
Best for: DIY builders replacing the rear wheel on a compatible 26-inch bicycle who already have or plan to source a 48V battery
Not ideal for: Riders with another wheel size, an incompatible rear fork, or a preference for a complete kit with battery included
- Voltage:48V
- Power:1000W
- Wheel size:26 inches
- Motor type:Brushless, gearless hub motor
- Torque:45 N·m
- Claimed maximum speed:53 km/h
- Weight:10.4 kg net
- Battery compatibility:48V 17–20Ah lithium or lead-acid; battery not included
Our verdict“Choose this kit for a focused 26-inch rear-wheel conversion if you can supply a compatible battery and accept the added wheel weight.”
Varstrom 48V 1000W/1500W Front or Rear Hub Motor E-Bike Conversion Kit
Varstrom is the power-focused hub option here, with a 1000W front configuration and 1000W or 1500W rear choices. It covers 26-inch, 27.5-inch, and 700C wheels, while its sine-wave controller and disc-brake compatibility suit buyers whose build matches the listed dimensions. Against the BAFANG 48V 500W/750W kit, Varstrom offers higher power and torque options; BAFANG, in turn, spans more wheel sizes and has walk assist listed. Varstrom’s fit is specific: front dropout width is 101–109 mm, and rear width varies by motor choice. Battery and LCD display may be optional, so check the selected configuration before planning a build. Its claimed speeds reach 70 km/h for the 1500W option, but that figure should not be treated as a suitable or lawful speed for every bike or location.
Pros:- Offers front 1000W and rear 1000W or 1500W configurations
- Supports 26-inch, 27.5-inch, and 700C wheels
- Sine-wave controller is included
- Supports disc brakes and up to 10 speeds
Cons:- Battery and LCD display may be optional
- Dropout width must match the chosen motor configuration
- The 1500W option’s claimed maximum speed may exceed what a particular bike or local rules allow
Best for: Experienced builders with a compatible disc-brake bicycle who want to compare higher-output front or rear hub configurations
Not ideal for: Riders with wheel sizes outside the listed range, mismatched dropout widths, or a need for a battery and display in the package
- Voltage:48V
- Motor options:1000W front; 1000W or 1500W rear
- Maximum torque:66 N·m (1000W); 78 N·m (1500W)
- Claimed maximum speed:55 km/h (1000W); 70 km/h (1500W)
- Wheel sizes:26 inches, 27.5 inches, 700C
- Controller:Sine-wave; 30A maximum (1000W), 35A (1500W)
- Dropout widths:Front 101–109 mm; rear 132–139 mm (1000W), 138–146 mm (1500W)
- Brake and gearing compatibility:Disc brakes; up to 10 speeds
Our verdict“Choose Varstrom if your frame and wheel fit the listed measurements and you want more hub-motor power options than the BAFANG 500W/750W kit offers.”
BAFANG BBS02B/BBS-HD Mid-Drive Electric Bike Conversion Kit
The BAFANG mid-drive stands apart from the wheel-motor kits because it mounts at the bottom bracket and offers up to 160 N·m of listed torque. That makes it the strongest fit in this batch for riders prioritizing a high-torque mid-drive layout over the simpler wheel swap offered by the 26-inch 1000W rear hub kit. Buyers can select 500W, 750W, or 1000W motors and choose among several bottom-bracket lengths, but the frame must match the specified measurements and use a chain drive. The kit supports throttle, pedal assist, and standard cycling modes. Battery and display may be separate selections, and the stated 73 mm screws are not included, so the purchase needs more parts checking than a more contained package. I would shortlist it for a compatible build where the mid-drive format is the priority.
Pros:- Available in 500W, 750W, and 1000W motor options
- Listed torque options reach 160 N·m
- Supports throttle, pedal assist, and standard cycling
- Fits several stated bottom-bracket lengths
Cons:- Battery and display may need to be selected separately
- 73 mm screws are not included
- Requires a compatible battery and XT60 connector
Best for: Experienced DIY builders with a chain-driven bicycle and a measured compatible bottom bracket who want a torque-focused mid-drive
Not ideal for: Owners of bicycles with incompatible bottom brackets or other drivetrains, or buyers expecting a battery, display, and every mounting screw in the kit
- Motor options:500W, 750W, or 1000W
- Torque options:100, 120, or 160 N·m
- Claimed maximum speed:Up to 45 km/h
- Bottom-bracket lengths:68–73 mm, 100 mm, or 120 mm
- Bottom-bracket inner diameter:33.5–36 mm
- Battery compatibility:48V or 52V
- Battery connector:XT60 male
- Compatible brakes:Disc or V-brakes
Our verdict“Choose this BAFANG mid-drive for a compatible chain-driven bike when torque and a bottom-bracket-mounted motor matter more than a simpler hub-wheel swap.”
BAFANG BBS02B 48V 750W Mid-Drive Electric Bike Conversion Kit
The BAFANG BBS02B mid-drive is the strongest fit here for riders who want climbing help across varied terrain: its stated 120 N·m of torque is substantially higher than the 65 N·m front-hub BAFANG 500W kit. Because it drives through the bike’s drivetrain, it suits compatible mountain, road, and commuter bikes better than a wheel-specific conversion. The tradeoff is fit: the bottom bracket must measure 68–73 mm, and carbon-fiber frames and pedal-brake bikes are excluded. This kit also asks buyers to check their power-source compatibility for its communication features, and the display is optional. Compared with the 1500W 20-inch rear-hub kit, this pick gives more clearly specified bike-fit criteria and three riding modes, but less stated motor power.
Pros:- Stated 120 N·m torque suits steep climbs and varied terrain.
- Offers throttle, pedal-assist, and standard cycling modes.
- Fits several bike styles when bottom bracket dimensions match.
- Includes installation components and a headlight.
Cons:- Does not fit carbon-fiber frames or bikes with pedal brakes.
- Power-source communication features require a compatible power source.
- Display is optional.
Best for: Riders converting a compatible non-carbon bike who regularly climb hills and want throttle, pedal-assist, and standard cycling modes.
Not ideal for: Owners of carbon-fiber or pedal-brake bikes, or anyone whose bottom bracket falls outside 68–73 mm.
- Motor:BAFANG BBS02B mid-drive
- Voltage:48V
- Power:750W
- Torque:120 N·m
- Bottom bracket width:68–73 mm
- Bottom bracket internal diameter:33.5–36 mm
- Stated maximum speed:Up to 45 km/h
- Riding modes:Throttle, pedal assist, standard cycling
Our verdict“Choose this mid-drive if your bike meets the fit requirements and climbing torque matters more to you than a higher stated wattage.”
BAFANG 48V 500W Front Wheel E-Bike Conversion Kit with Battery
For a first conversion, this BAFANG front-hub kit keeps the installation proposition approachable: it arrives 90% pre-assembled and supports throttle, pedal assist, walk assist, and traditional cycling. Its 500W motor and stated 65 N·m torque make it a more moderate option than the 1000W Ktaxon 24-inch front-wheel kit, while its support for V-brakes or disc brakes covers common setups. Fit is the key filter: the fork needs 100 mm quick-release spacing. Battery capacities vary by option, and the LCD display and Bluetooth connectivity are optional, so buyers should confirm which parts their chosen configuration includes. Compared with the BBS02B mid-drive, this kit avoids a bottom-bracket fit check but puts the motor in the front wheel.
Pros:- Mostly pre-assembled to simplify DIY installation.
- Supports throttle, pedal assist, walk assist, and traditional cycling.
- Compatible with V-brakes or disc brakes.
- Battery options include locks, USB ports, and LED indicators.
Cons:- Requires a 100 mm quick-release front fork.
- Battery capacities vary by selected option.
- LCD display and Bluetooth connectivity are optional.
Best for: DIY commuters with a 100 mm quick-release fork who want a mostly assembled front-hub kit and several assist modes.
Not ideal for: Riders with thru-axle or other non-compatible forks, or buyers who need a fixed battery capacity and included display.
- Motor type:Brushless geared front hub
- Voltage:48V
- Power:500W
- Maximum torque:65 N·m
- Stated maximum speed:40 km/h
- Fork compatibility:100 mm quick-release front forks
- Brake compatibility:V-brakes or disc brakes
- Stated range:Up to 50 km+
Our verdict“Pick this kit if your fork matches and you value an approachable front-wheel conversion with multiple riding modes.”
48V 1500W Electric Bike Conversion Kit with 20-Inch Rear Hub Motor
This 20-inch rear-hub kit has a clear niche among the roundup: it is built around a compact wheel and pairs a 1500W gearless motor with a seven-gear setup, PAS sensor, LCD display, and power-off brake levers. Those included controls give it a more specified package than the Ktaxon 24-inch front-wheel kit, which leaves the battery out and fits only a narrower wheel and dropout combination. The stated load capacity of about 330.69 lb may also suit heavier builds, though it does not establish compatibility with any particular frame. Battery fit and range are not described, and the listing does not spell out frame requirements; those gaps make this a less certain choice than the BAFANG BBS02B, whose bottom-bracket dimensions are provided. Confirm wheel and frame fit before buying.
Pros:- Includes a PAS sensor and LCD display.
- Gearless brushless motor is described as quiet.
- Stated load capacity is about 330.69 lb.
- Power-off brake levers are included.
Cons:- Battery compatibility and range are not specified.
- Specific frame compatibility is not detailed.
- The 20-inch wheel size limits it to compatible builds.
Best for: Builders converting a compatible 20-inch bike who want a rear hub, included display, PAS sensor, and brake cutoffs.
Not ideal for: Riders who need documented battery compatibility, a stated range, or detailed frame-fit guidance before selecting a kit.
- Voltage:48V
- Motor power:1500W
- Wheel size:20 inches
- Motor type:Brushless, gearless rear hub motor
- Gears:7
- Maximum load capacity:About 330.69 lb
- Efficiency:Over 82%
- Included features:PAS sensor, LCD display, power-off brake levers
Our verdict“Choose this for a compatible 20-inch build when the included controls and stated load capacity fit your priorities.”
Ktaxon 48V 1000W 24-Inch Front-Wheel E-Bike Conversion Kit
The Ktaxon 24-inch front-wheel kit is the most specific match for a bike with the right wheel and fork dimensions: it combines a 1000W gearless hub, LCD display, PAS, and four riding modes. Its display reports battery power, speed, mileage, mode, and error codes, giving riders more at-a-glance information than the 20-inch 1500W rear-hub kit, whose listed features mention an LCD but not what it displays. That convenience comes with strict fit limits: the bike needs a 24-inch wheel and 3 15/16-inch front dropout spacing. The battery is not included, and the stated 220-pound weight recommendation is lower than the other kit’s stated 330.69-pound load capacity. I’d shortlist it for a matching bike, not as a flexible conversion for mixed wheel sizes.
Pros:- 1000W brushless, gearless front hub motor.
- LCD reports battery power, speed, mileage, mode, and error codes.
- Offers throttle, presets, PAS, and manual riding modes.
- Brake signal cuts motor power.
Cons:- Battery is not included.
- Requires a 24-inch wheel and specified front dropout spacing.
- Stated maximum weight recommendation is 220 pounds.
Best for: Owners of a compatible 24-inch bike who want a front-wheel conversion with an informative display and PAS.
Not ideal for: Riders with other wheel sizes, mismatched front dropout spacing, or a need for a battery in the kit.
- Motor power:1000W
- Voltage:48V
- Wheel size:24 inches
- Mounting:Front wheel
- Front dropout spacing:3 15/16 inches
- Maximum weight recommendation:220 pounds
- Brake style:Caliper
- Battery:Not included
Our verdict“Choose this kit if your 24-inch bike matches the front dropout measurement and you want a display-rich front-wheel setup.”
How We Picked
I evaluated each kit against four buyer-facing criteria. Power and real-world performance came first: a 2000W hub motor serves a very different rider than a 500W front hub, so I judged each kit against its intended use rather than raw wattage alone. Fit and compatibility mattered just as much — wheel size, bottom bracket type, and fat-tire support determine whether a kit will even bolt onto your bike, and kits with narrower fitment ranked lower for general buyers. Completeness of the package was the third filter: kits that include a battery, controller, wiring harness, and display deliver a far smoother build than motor-only boxes that leave you sourcing parts. Finally, I weighed installation difficulty and maintenance, because a kit that sits unassembled in a garage helps no one.
The ranking order reflects a simple philosophy: the best kit is the one a buyer can actually install, afford, and live with. That’s why the mid-drive BAFANG kits lead despite higher cost — their performance-per-installation-hour is unmatched — while high-wattage budget hub kits fill the value tier and gas kits occupy a niche for riders who specifically want fuel power. Front-hub starter kits rank lower on performance but earn their place as the gentlest on-ramp for beginners.
Factors to Consider When Choosing Best Bike Conversion Kits
Before you commit to any kit in this roundup, step back and think about the bike you own and the rides you actually take. The most common mistake I see is buyers chasing peak wattage when motor placement, battery strategy, and frame compatibility decide far more of the final experience.Hub Motor vs. Mid-Drive: The Decision That Shapes Everything
Hub motors place the power in a wheel — cheap, sealed, and nearly maintenance-free, but they add rotating mass exactly where you don’t want it and ignore your gears. Mid-drives like the BAFANG BBS series drive the crank instead, multiplying motor power through your drivetrain for dramatically better hill climbing and a bike that still handles like a bike. The tradeoffs cut both ways: mid-drives cost more, require bottom-bracket work, and chew through chains faster, while hub kits can be swapped back out in an afternoon. Riders in flat cities can happily live with a hub motor; anyone facing regular steep grades will feel the difference within the first week. Decide this question before anything else, because it narrows the field more than any other choice.
The Battery Trap: Why the Cheapest Kit Is Rarely the Cheapest Build
Many high-wattage kits advertise an attractive price that excludes the single most expensive component: the battery. A quality 48V pack with enough capacity for real commuting range can cost as much as the motor kit itself, and pairing a 1000W or 2000W motor with an undersized or cheap cell pack leads to sag, cutouts, and short pack life. Match the battery’s continuous discharge rating to the motor’s draw — a 2000W hub motor is wasted on a pack built for a 500W system. If total budget is tight, a lower-wattage kit that includes a matched battery often delivers a better ownership experience than a powerhouse motor running on a compromise pack. Always calculate the complete build cost before comparing sticker prices.
Wheel Size and Frame Compatibility: Check Before You Click
Conversion kits are built around specific wheel diameters and widths, and there is no fudge factor — a 26-inch hub motor will not work on your 20-inch folding bike, and a standard-width motor won’t fit a 4-inch fat tire. Measure your wheel rim diameter and tire width from the sidewall, confirm your dropout spacing for rear hubs, and for mid-drives measure your bottom bracket shell width and type. Suspension forks with thin aluminum legs can also be a problem for front hub motors. These compatibility checks take ten minutes and prevent the most common return in this category. When in doubt, a mid-drive kit sidesteps wheel-size issues entirely since it replaces your bottom bracket, not your wheel.
Electric vs. Gas: The Honest Comparison
The 2-stroke engine kits in this roundup solve a problem electricity currently can’t: unlimited range limited only by a fuel can, and refueling in seconds. But the ownership experience is a different world — loud operation, gasoline smell, oil mixing, carburetor tuning, vibration, and legal restrictions in many cities that treat motorized bicycles differently from e-bikes. Electric kits are nearly silent, need no consumables, and start every ride with zero fuss. My honest guidance: choose gas only if you regularly ride beyond battery range, enjoy wrenching on engines, and have confirmed your local laws. For everyone else, modern 48V electric systems have closed the performance gap at a lower daily-hassle cost.
Installation Skill: Match the Kit to Your Toolbox
Front hub kits are a one-evening job with basic hand tools — remove the wheel, lace or swap in the motor wheel, connect a controller, done. Rear hub kits add derailleur adjustments and dropout alignment, which takes patience the first time. Mid-drives demand bottom bracket removal, torque-arm-level care with chain alignment, and often new cranks. Gas engine kits require the most mechanical aptitude: fuel line routing, sprocket mounting to the rear wheel, chain tensioning, and carburetor tuning that may take several weekends to get right. A common mistake is buying ambition instead of matching the install to your actual skill and available time. Factor in whether a local bike shop will touch a converted bike — many won’t service gas builds at all.
Local Laws and Power Limits: Know Before You Build
A 1000W or 2000W motor may classify your converted bike as a moped or motorcycle where you live, triggering registration, licensing, helmet, and insurance requirements — while a 500W kit stays within typical e-bike definitions. Power limits vary widely by country, state, and even city, and they’re usually written around continuous rated wattage and top assisted speed. Throttle-only operation is restricted in some places where pedal-assist is fine. This is a boring step that protects your investment: a build that’s illegal to ride on your local paths isn’t a bargain at any price. Check your regulations before choosing between the 500W entry kits and the high-output options in this guide.
Frequently Asked Questions
Is a 1000W or 2000W conversion kit actually better than a 500W one?
Only for specific use cases. Higher wattage means faster acceleration, higher top speed, and better performance hauling cargo or climbing long steep hills, but it drains batteries faster, adds weight, and may push your bike outside legal e-bike classifications. A quality 500W system — especially a mid-drive like the BAFANG BBS02B in the lower setting — handles typical commuting, rolling hills, and recreational riding with plenty of margin. Most riders overestimate the wattage they need and underestimate how much battery capacity they’ll want. Choose based on your terrain and legal limits, not the biggest number on the box.
Do I need to buy a battery separately, and how do I choose one?
Most kits in this roundup ship without a battery, so yes — plan for it. Match the voltage exactly (a 48V motor needs a 48V pack), then choose capacity in amp-hours based on range: roughly, a 48V 13Ah pack gives 25–40 miles of moderate assist depending on wattage, terrain, and rider weight. Also check the pack’s continuous discharge current — a 2000W motor can pull over 40 amps, which cheap packs can’t sustain, causing voltage sag and shutdowns. Buy from a reputable brand with a real battery management system, since the pack is both the most expensive and most safety-critical part of the build.
Will a conversion kit fit my specific bike?
It depends on three measurements. For hub kits: your wheel diameter (must match the motor wheel exactly, e.g., 26-inch or 20×4-inch fat tire), and your fork or frame dropout width. For mid-drive kits like the BBS series: your bottom bracket shell width and type, which must be a standard threaded design — many press-fit or exotic shells won’t accept one. Carbon frames and forks are generally a poor match for hub motors due to dropout strength. Before ordering, note the numbers printed on your tire sidewall and measure the gap between your dropouts. If your bike has an unusual frame, the mid-drive route or a front-hub kit on a steel fork is usually the safest bet.
Are 2-stroke gas engine kits a good way to save money over electric?
Upfront, sometimes — but total ownership tells a different story. Gas kits need fuel, two-cycle oil, spark plugs, chain lubrication, carburetor tuning, and periodic gasket work, while electric kits need essentially nothing beyond normal bike maintenance. Gas builds also bring noise, exhaust smell, vibration, and frequent legal gray areas that can get you fined or your bike impounded in some jurisdictions. Where gas genuinely wins is range and refuel speed: no charging wait, no battery degradation, and the ability to carry extra fuel for very long rides. Choose gas if you’re mechanically inclined and ride where motorized bicycles are legal; otherwise electric is the lower-hassle, often cheaper long-term path.
Can I install a conversion kit myself, or do I need a shop?
Most electric hub kits are realistic DIY projects if you can change a flat tire and follow wiring diagrams — front hub kits typically take one to three hours, rear hubs a bit longer due to derailleur and brake adjustments. Mid-drives are a moderate step up, requiring bottom bracket tools and careful chain line work, but a capable home mechanic can manage a weekend install. Gas engine kits are the outlier: mounting the sprocket, routing fuel lines, and tuning the carburetor demand real mechanical experience, and first builds often need troubleshooting before running right. One caveat: many bike shops decline to work on converted bikes, especially gas builds, so if you’re not comfortable maintaining it yourself, factor that into which kit you choose.
Conclusion
After comparing all 14 kits, the right choice comes down to what kind of builder you are. For best overall, the BAFANG BBS02B/BBS-HD mid-drive kit stands apart — it turns a standard bike into something that rides like a purpose-built e-bike, with gearing leverage that hub motors can’t match. The best value pick is the 48V 1000W rear hub kit, which delivers genuine commuting power at a no-frills price, provided you budget for a separate battery. Best premium goes to the BAFANG BBS-HD configuration for riders who want maximum torque and long-term durability for demanding terrain.
Beginners should start with the BAFANG 48V 500W front kit with battery — the matched battery and simple install remove the two biggest failure points of a first build. For specific needs: fat-tire riders get real power from the HuaShuani or LTIGOAW 2000W 20-inch kits, smaller-wheel commuters should look at the 48V 1500W 20-inch kit, and the 2-stroke gas kits remain the only choice for off-grid range without a charging cord. Whatever you pick, confirm your wheel size and local power laws before ordering — the best conversion kit is the one that fits your bike and your streets.
Fall Picks
fall essentials
As an affiliate, we earn on qualifying purchases.
